New   Kioti DK4520

back to top

Engine

Model: 3HT-TM4B	Engine Manufacturer: KIOTI
Power: 44.90 hp (33.50 kW)	Displacement: 111.40 cu. in. (1,826 cc)
RPM: 2,600 rpm	Fuel Type: Diesel
Aspiration: Intercular	Fuel Capacity: 11.90 gal (45 L)

back to top

Transmission

Transmission: Manual: Synchro Shuttle	Shuttle: Dry Single Stage
Main Gear: Dry Single Stage	Travel Speeds Forward: 8
Travel Speeds Reverse: 8	Travel Speeds Minimum Speed: 1.29 mph (2.08 km/h)
Travel Speeds Maximum Speed: 16.70 mph (26.90 km/h)	Travel Speeds Min Reverse Speed: 1.26 mph (2.03 km/h)
Travel Speeds Max Reverse Speed: 16.30 mph (26.20 km/h)

back to top

PTO

PTO Type: Independent	PTO Power: 38.90 hp (29 kW)
Rear Speed: 540	Mid Speed: 2,000

back to top

Drive Train

Brakes: Wet Multi Disc	Clutch: Dry Single Stage
Steering: Hydrostatic Power Steering

back to top

Hydraulics

Pump: Gear	Pump Capacity: 14.70 gpm (55.10 lpm)
Lift Capacity: 2,716 lb (1,232 kg)

back to top

Hitch

Type: Three Point	Category: Category 1
Control Type: Position	Lift Capacity: 2,716 lb (1,232 kg)

back to top

dimensions

Length with Hitch: 124.30 in (3,157 mm)	Width: 62.80 in (1,596 mm)
Wheelbase Length: 71.30 in (1,810 mm)	Ground Clearance: 14.50 in (368 mm)
Front Tread: 49.40 in (1,254 mm)	Rear Tread: 49.30 in (1,251 mm)
Turning Radius: 8.56 ft (2.60 m)	Weight: 3,373 lb (1,530 kg)
Height: 96.80 in (2,458 mm)
